Inspection principle

The overall equipment integrates mechanical mechanism, visual optical hardware and detection system software, rejecting and counting devices for defective products. After the product is produced, the product is transported to the inspection station by the gasket machine belt for sequential inspection.

After comparing and analyzing the image processing software and the standardized sample, the good product and the defective product are judged. The defective product is automatically eliminated online, and the counting function can be realized after the finished product is inspected. After the product inspection, it is transported by the export conveyor line to the back-end for the next packaging process. The equipment can operate 7*24 hours a day, instead of manual inspection, which can greatly improve production efficiency and product quality.

Application of cameras

• For the detection of the top surface of the bottle cap, the top surface of the bottle cap is suspended by the vacuum adsorption belt, and a set of industrial cameras are installed below, and with the use of visual light source, the image of the top surface of the bottle cap is collected for processing.
• For the detection of the concave surface of the bottle cap, a set of industrial cameras are installed above the bottle cap, and with the use of visual light source, the image of the concave surface of the bottle cap is collected for processing.
• For the detection of the outer side of the bottle cap, 4 sets of industrial cameras are installed around the bottle cap to form a 360-degree ring surface detection, which is used in conjunction with the visual light source, and the side image is collected and processed by the system.
•

CCD camera image display

Advantages of CCD camera

1)High detection accuracy and fast detection efficiency:CCD visual inspection equipment uses machine control according to the system, with small error and high detection rate.

2)Wide detection range to detect cosmetic defects and dimensional measurements:The multi-station inspection method can accurately measure the outline, specifications, appearance defects, product aspect ratio and other performance parameters of the product to be inspected at one time.

3)Improve product quality and error rates:Vision inspection equipment is based on system control, which can distinguish good products from bad products through automatic inspection technology, and then automatically place them in different parts.

4)Save labor costs and enable high repetitive work:CCD visual inspection can work stably for a long time, it is difficult for human eyes to observe the same object for a long time, and machine vision can perform measurement, analysis and recognition tasks for a long time. And it can continue to work, with low requirements for the natural environment of the application, in addition to saving product costs, it also greatly improves productivity.
