PCB AOI Automatic Inspection System Optical Principle Image Analysis

PCB AOI Automatic Inspection System Optical Principle Image Analysis

  • PCB AOI Automatic Inspection System Optical Principle Image Analysis
  • PCB AOI Automatic Inspection System Optical Principle Image Analysis
PCB AOI Automatic Inspection System Optical Principle Image Analysis
Product Details:
Place of Origin: China
Brand Name: KEYE
Certification: NO
Model Number: KVIS-DR
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: Negotiable
Packaging Details: Fumigation-free wood
Delivery Time: 4 to 6 weeks
Payment Terms: L/C, T/T
Supply Ability: 1 set per 6 weeks
Contact Now
Detailed Product Description
Applications: AOI Devices With Optical Principle Image Analysis Brand: KEYE
Weight: 300kg Function: PCB AOI Machine
Selling Points: Compressed Air (non-pollution) Air Pressure: 0.2Mpa-0.5Mpa
Package: Wood Packing Key Technology: AI Inspection
Material: SS304 Packing: Plywood Carton
High Light:

PCB AOI Automatic Inspection System

,

Optical Principle Image Analysis Inspection System

AOI Devices with Optical Principle Image Analysis Automatic Inspection System



System features

1. High-efficiency detection, not affected by PCB mounting density;
2. For different detection items, combined with optical imaging processing technology, there are different detection methods;
3. Simple and user-friendly operation interface, which can be operated without professionals;
4. Display the actual error image, which is convenient for the operator to carry out the final visual check;
5. It can count NG data and analyze the causes of defects, and feedback process information to the operator in real time.



Product Background

The full name of AOI is automatic optical inspection, which is a device based on optical principles to detect common defects encountered in welding production. AOI is a new type of test technology that has emerged in recent years, but it has developed rapidly. Many visual inspection equipment manufacturers have launched AOI test equipment.

PCB AOI Automatic Inspection System Optical Principle Image Analysis 0

During automatic detection, the machine automatically scans the PCB through the camera, collects images, and compares the tested solder joints with the qualified parameters in the database. After image processing, the defects on the PCB are checked, and the defects are displayed/marked through the display or automatic sign. , for maintenance personnel to repair.



Equipment advantages

With the rapid development of AOI visual inspection today, automatic optical inspection (AOI) is an effective inspection method for industrial automation, and gradually replaces traditional manual inspection, and is widely used in LCD/TFT, transistor and PCB industrial processes. It effectively detects placement quality, solder joint quality, etc.



By using AOI as a tool to reduce defects, find defects early in the assembly process and avoid sending defective products to the final assembly process, it will reduce repair costs and avoid scrapping of non-repairable circuit boards, reducing costs for manufacturing companies and It ensures the stability of product quality and improves product competitiveness.


Mechanical part

The mechanical part is the core component of the system, which carries all the transmission devices and electronic hardware (industrial cameras, light sources, industrial computers, touch screens, electrical boxes, etc.). The conveyor is controlled by a servo motor, and the image capture is accurate. The equipment is equipped with two defective product inlets to separate serious defective products (such as drum bottom, oblique leather tip, etc.) and general defective products.

1.AI algorithm: high stability, adapting to the environment and background disturbance; different defect samples can be automatically identified after training.

2.Dataization: Independent database, save multiple samples, analyze non-good products, and retain history.

3.Multi-orientation: 360 ° comprehensive inside and outside the sampels

4.High precision: detection accuracy can reach 99%.

5.Modularization, can flexibly increase or decrease the detection function according to customer actual needs.

6.Easy to operate: It is easy to operate and easy to maintain.

7.Safety: Medical grade material manufacturing, fully compliant with medical supplies production environment.

PCB AOI Automatic Inspection System Optical Principle Image Analysis 1
